KWC DVS Stainless Steel DUHS Hospital Disposal Unit 1000 or 1600mm Wide

A DUHS, HTM 64 Standard hospital disposal unit manufactured by KWC DVS in 1.2mm thick, grade 1.4301 (304) stainless steel with a satin polish finish. Fitted with sluice hopper, the top is turned down on all four edges and incorporates a wet area recess. The tap holes and drainer position (right/left) are optional.

This hospital disposal unit can be mounted on either stainless steel cantilever brackets or front leg supports give a working height of 900mm and have adjustable feet which can be screwed to the floor for extra stability.

Variations:

• G22016L : 1000mm x 600mm Left Hand Drain
• G22016R : 1000mm x 600mm Right Hand Drain
• G22018L : 1600mm x 600mm Left Hand Drain
• G22018LT : 1600mm x 600mm Left Hand Drain with tap holes
• G22018R : 1600mm x 600mm Right Hand Drain
• G22018RT : 1600mm x 600mm Right Hand Drain with tap holes

Features:

• A DUHS hospital disposal unit manufactured from 1.2mm thick, grade 1.4301 (304) stainless steel with a satin polish finish
• The top is turned down on all four edges and incorporates a wet area recess
• Fitted with a sluice hopper at one end, the hopper has a 110mm dia. outlet which can accept a P or S trap, available as an extra
• The wash up bowl does not have an overflow, flush grated wastes are available as an extra, also available are 9 litre capacity plastic cisterns with plastic downpipe, these are fitted with a 13mm HP brass valve, plastic float and CP metal flushing lever handles.
• The unit should only be fed from a cistern or tank water supply.
• L or R after the code number refers to the handing of the drainer ie. left or right when facing front of unit.
• HTM 64 STANDARD
• Optional Left or Right hand drainer (please specify)
• Tap holes optional (please specify)
• Note : A wash up bowl is positioned next to the sluice hopper and is prepared for a 38 mm waste outlet.  The 1000mm does not include a wash up bowl.
