Delabie mirror cabinet with integrated tap, soap and drier

Delabie's behind-the-mirror (BTM) combination unit is a modular system offering an all-in-one wash station with touch-free washroom accessories that look great and offer outstanding space-saving benefits.  Offered with a 10-year warranty, this is an ideal product for a range of commercial settings.

Expertly engineered using Delabie's leading tap and accessories technology, the mirror cabinet is configured in 600mm or 800mm wide units. It is customisable with either high-speed, low-energy hand driers or paper towel dispensers.  Each unit comes as standard with infrared sensor taps and soap dispensers - all concealed behind the single-piece mirror.  To create a premium feel, each unit has an LED strip light to create a halo effect when the user is washing their hands.

The Delabie mirror system ensures an integrated, easy-to-use, and clutter-free handwashing experience for commercial washroom users. Eliminating the need to move to either wash or dry your hands, this innovative mirror system significantly reduces soap and water residue on the washroom floor, which can cause slips and trips. Partnered with our Solid Surface wash troughs, the hand wash station is ideal in commercial buildings such as shopping centres, hotels, restaurants, offices, and other premium, high-foot-traffic areas.

The units are quick and easy to install, each with adjustable hinges, a 230V / 50-60Hz transformer electrical connection, stainless steel screws, and a single water connection located inside each cabinet.  Several cabinets can be installed side-by-side to create a mirror wall (linking screws are provided).  Replenishment of the large 5-litre soap tank and paper towel holder is simplified through the accessible hinged mirror, which opens and closes using a standard Delabie key.

Other benefits include an internal storage shelf, a janitor flush every 24 hours after the last use, and an anti-vandal function that prevents repetitive overuse/misuse. The stylish unit is made to match the Delabie Black Magic collection, all sold at Commercial Washrooms.

Specification

• Mirror cabinets have four functions: mirror, electronic tap, soap dispenser, and electric hand dryer
• Designer cabinet with matte black melamine and 304 stainless steel finish
• Comes complete with Delabie's nano TMV (732115) and connector (808012.2P)
• Touch-free for improved hygiene: soap dispenser, tap and hand dryer are activated automatically when an infrared sensor detects hands
• 4mm thick glass mirror and black glass strip with illuminated pictograms
• The LED strip lights the basin below
• A vandal-resistant model with standard DELABIE key
• Anti-blocking: stops automatically if used continuously
• Internal storage shelf
• Several cabinets can be installed side-by-side to create a mirror wall: linking screws are provided
• Suitable for people with reduced mobility
• Dimensions: 600 x 223 x 1,000mm
• Weight: 39kg
• 10-year warranty
• CE marked

Automatic soap dispenser

• No-waste pump dispenser
• Large capacity tank: 5 litres
• Suitable for vegetable-based liquid soap with a maximum viscosity of 3,000 mPa.s or specific foam soap.

Electronic basin tap

• Reduced stagnation solenoid valve
• Flow rate 4 lpm
• Scale-resistant flow straightener
• Duty flush (~60 seconds every 24 hours after the last use)
• Stopcock.
• We recommend a PREMIX mixer.

Air-pulse hand dryer

• High speed: dries in 10 - 12 seconds
• Pulsed air at 360km/h. Airflow: 36 l/second
• Low energy consumption: 704W
• Noise level: 74 dBA
• Class I, IP23
• 3-year warranty
