Washbasin with Exposed Trap Integrated Plumbing System (IPS) Module
The Commercial Washrooms wall-hung basin with an exposed trap Integrated Plumbing Systems (IPS) offers a complete solution for projects requiring concealed plumbing. Made to measure to either full or half room height (including a lid to conceal the top of the unit), our pre-plumbed IPS is delivered to the site as a factory-assembled unit for fast installation.
Choose from a panel finish in either melamine-faced chipboard (MFC), High-Pressure Laminates (HPL) or Solid Grade Laminates (SGL).
30 days free credit with
Buy Now, Pay Later, options at checkout
The Commercial Washrooms wall-hung basin with an exposed trap Integrated Plumbing Systems (IPS) offers a complete solution for projects requiring concealed plumbing. Made to measure to either full or half room height (including a lid to conceal the top of the unit), our pre-plumbed IPS is delivered to the site as a factory-assembled unit for fast installation.
Choose from a panel finish in either melamine-faced chipboard (MFC), High-Pressure Laminates (HPL) or solid-grade laminates (SGL). Colours are from our standard Polyrey colour range (PDFs attached).
The systems are available to suit half or full-room heights (up to 2400mm). They are manufactured to order and can, therefore, suit site-specific measurements and bespoke room sizes.
With a simple five-step installation, it is easy to specify and install and can save up to 20% in cost when compared to traditional methods while at the same time saving valuable time on site.
The IPS pre-plumbed manufactured module includes a self-supporting frame, plumbing, sanitary ware, supply and soil connections and all fixings. On-site, the modules are lightweight and easy to handle, making installation even quicker.
To complete the job, a qualified plumber can make the final connection between the water supply and soil pipework to the pre-plumbed cistern and sanitary ware. These will be fitted by trained washroom installers and commissioned by qualified plumbing contractors.
An additional delivery charge will apply, depending on site location. See the attached location map for guidance.
Wall-hung basin module pack includes:
- Standard IPS metal frame and panel set.
- Olympus white 520mm basin.
- Chrome-plated 32mm bottle trap.
- Inta NC230CP Non-Concussive Mixer Tap
- Flexi hot and cold water connector with shut-off valve.
- All necessary pipes, fittings and fixtures
Not included: First Fix Plumbing pipework.
