Healthcare Wash Basin IPS Unit with Hinged and Lockable Panels
Our hinged and lockable healthcare IPS unit is designed for use in any hospital or healthcare setting where hand washing is necessary. It is available as a complete Integrated Panel System (IPS) unit that includes the necessary medical tap, basin, and waste configuration.
Our standard unit is made to measure with a robust steel frame and hinged SGL access panels. Armitage Shank's Markwik tap (lever or sensor-operated options) and Contour 21+ basin are factory-fitted, meaning they are easy to install.
30 days free credit with
Buy Now, Pay Later, options at checkout
This pre-plumbed wash hand basin IPS duct set module is designed for use within a hospital or healthcare environment where infection control is required. Made to measure and suit your site's dimensions.
At the heart of each fully adjustable module is a self-supporting 16 gauge galvanised metal frame that can be securely fixed to the floor, walls, and ceiling. Available for installation in multiple scenarios - Recessed, between walls, one return end, and two return ends (boxed out).
Access panels are mounted on the frame with a rebated pivot hinge system and corresponding locks to 2 access panels. We also offer an option for access panels to be mounted with concealed lift-off clips.
All modules are produced to HBN00-10 and HTM64 specifications. Panels are manufactured as standard from impact-resistant, sanitised, antibacterial compact grade laminate for optimum hygiene, allowing appropriate cleaning chemicals and water to be used without affecting the life of the material.
Please select colours from the Polyrey Washroom Collection attachment. Alternative colours and laminate manufacturers are available on request.
Sanitary ware and Taps: Units are manufactured in the factory as an Integrated Panel System (IPS), delivered to site with Armitage Shanks sanitary ware pre-fixed. Alternatively, sanitary ware and brassware that are compliant with HBN and HTM can be ordered separately from the Commercial Washrooms website.
Armitage Shanks Medical Basin Included:
- S0430(HY) Contour 21+ 50cm back outlet washbasin, no tapholes, anti-splash and anti-microbial glaze
- S0386(67) Contour 21+ waste pack with SmartGuard for wall-mounted basin
- Basin fixing kit
Armitage Shanks Medical Tap Options:
- Lever operated: A6682(AA) Markwik 21+ panel mounted thermostatic basin mixer tap, single sequential lever, demountable with detachable spout
- Sensor operated: A6684(AA) HBN 00-10 HTM64 (TB H6) Markwik 21+ Panel Mounted Thermostatic Basin Mixer tap, Time Flow Sensor, demountable with detachable spout
The sanitaryware is mounted on sanitised antibacterial solid-grade laminate (SGL) panels, which are also abuse-resistant and impervious to water. They are also resistant to suitable cleaning chemicals (excludes harsh bleach). Panels are manufactured with minimal gaps to reduce edge surfaces.
IPS Frame and Panel Construction:
- Metal wall and floor fixing channels
- Sanitised antibacterial SGL panels
- Post-formed SGL vertical panelling
- Suitable for heavy use and wet environments
Dimensions:
- Typical sizes heights – 1500mm – 2800mm
- Typical sizes widths - 600mm – 900mm
- Standard depths -100mm – 300mm
