Healthcare Disposal Unit Duct Module
Made to measure hospital IPS duct set module. As standard, this disposal unit duct module measures 1950mm wide x 2400mm high x 200mm deep, but the dimensions are flexible. It is available with a choice of two return ends (boxed out), one return end (in a wall angle), or between walls (no return ends).
All modules are produced to HTM64 specification. Panels are manufactured as standard from impact-resistant, sanitised, antibacterial compact grade laminate for optimum hygiene, allowing appropriate cleaning of chemicals and water to be used without affecting the life of the material.
30 days free credit with
Buy Now, Pay Later, options at checkout
Made to measure hospital IPS duct set module. As standard, this disposal unit duct module measures 1950mm wide x 2400mm high x 200mm deep, but the dimensions are flexible. It is available with a choice of two return ends (boxed out), one return end (in a wall angle), or between walls (no return ends).
All modules are produced to HTM64 specification. Panels are manufactured as standard from impact-resistant, sanitised, antibacterial compact grade laminate for optimum hygiene, allowing appropriate cleaning of chemicals and water to be used without affecting the life of the material.
Sanitaryware and Brassware:
Includes the following:
- IPS Panel and metal frame set (x2)
- Hinged and lockable access panel (x2)
- S6551 (DU HS) Dee right hand slop hopper with sink, back inlet
- S4663 Flushpipe 850 x 35mm diameter for slop hopper
- B1684 Nimbus 21 bib tap extension 1/2" x 100mm pair
- S3626 Conceala 2 cistern 6-litre single flush syphon high-level side supply and internal overflow, lever with chain
- S3584 P trap outlet, plastic for slop hoppers
- S8925 (TRR2/P) Trap 1½" plastic resealing bottle with 75mm seal, multi-purpose outlet
- S8760 Waste 1½" un-slotted strainer waste, 50mm long, 75mm dia. brass
- S8270 (TB H1) Markwik ½" bib taps
- B1686 Nimbus 21 concealed bib tap wall mount, self-centralising installation, pair
Infection control:
- Sanitised antibacterial solid grade laminate panels
- Resistant Abuse
- Impervious to water
- Resistant to suitable cleaning chemicals
- Close fitting panels to minimise edge surfaces
Construction:
- Steel wall and floor fixing channels
- Sanitised antibacterial SGL panels
- Pivoting and lockable access panels
- Post formed SGL vertical panelling
- Suitable for heavy use and wet environments
