Cistermiser Vecta+ Wall Mounted Sensor Tap

The Cistermiser Vecta+ Wall Mounted Sensor Tap (VSS) helps to improve hygiene and prevent the transfer of pathogens with no-touch controls. It is easy to install, as a retrofit or in a new build installation.

With an infrared tap, the water only runs while your hands are in range, so these taps reduce wasted water, increase efficiency, save energy and reduce costs while maintaining reliability and high performance. Available in a polished chrome finish.

Made to high standards, with options for mains or battery power, out of the box as standard, this infrared sensor tap has a stylish and modern design, with highly intelligent electronics, that offer a safeguard against misuse and vandalism.

They provide the optimum in hygiene for the modern-day commercial washroom and come fitted with a 3.5lpm flow regulator as standard with a 5lpm flow regulator in the box, to support environmental building schemes such as BREEAM.

Features and benefits:

• Improved hygiene - reduce the risk of cross-contamination
• Non-touch – Intuitive and easy to use. These non-touch solutions are more hygienic and reduce the likelihood of pathogens
• Water and energy saving - the water only runs when your hands are within range, so there is less water to heat. Water saving and energy efficiency are more cost-effective
• Easy to install and maintain – chrome finished, easy to retrofit and swap out existing manual taps. External solenoid for easier servicing
• Mains and battery power - options out of the box
• Safety shutoff - after 60 seconds of continuous water activation, the tap will automatically shut off the flow of water to reduce the risk of flooding
• Smart shutoff - in the event of a power outage the device will automatically shut off the water flow to reduce the risk of flooding
• Support - environmental building schemes
• Ease of use - for elderly or people with reduced mobility

Technical Information:

• Dimensions - 243mm W x 38mm H x 38mm D, Spray nozzle height above basin surface (variable, see installation guide), Spray nozzle projection from tap body 207mm
• Mounting requirements - Any vertical surface 10mm to 40mm in thickness, requires a hole of 26-32mm in diameter
• Sensor range - Up to 18cm
• Run-on time - 2 seconds
• Power requirements - 6V DC from 4 x alkaline AA (LR6) batteries or 6V DC regulated from a mains adaptor (1A fused spur required)
• Normal Battery life - 300,000 activations (flashing LED indicates batteries are low and need to be replaced)
• Ambient temperature range - Operating: 0 to 40°C. Storage: -25 to 40°C.
