Floor Standing Stainless Steel Urinal Trough for Concealed Cistern
This slab urinal trough is one of few available in the UK commercial washroom market that is installed by mounting to the floor. Manufactured from high quality brushed stainless steel it comes as a complete pack and includes a plastic autoflush cistern and a stainless steel sparge flushing pipe. Available in a choice of lengths, including 1.2m, 1.8m and 2.4m.
Designed for installation where the urinal cistern can be concealed either behind a service void wall or within an IPS duct set.
30 days free credit with
Buy Now, Pay Later, options at checkout
This slab urinal trough is one of few available in the UK commercial washroom market that is installed by mounting to the floor. Manufactured from high quality brushed stainless steel it comes as a complete pack and includes a plastic autoflush cistern and a stainless steel sparge flushing pipe. Available in a choice of lengths, including 1.2m, 1.8m and 2.4m.
Designed for installation where the urinal cistern can be concealed either behind a service void wall or within an IPS duct set. The flush pipes are installed as a back inlet option meaning the only item visible is the urinal trough itself. Top inlet also available.
The trough has a raised integral waste channel and removable access panel for above floor waste plumbing. Waste can be left or right hand with a 50mm chrome plated hinged domed waste outlet. Two or more urinals may be fitted together on the same wall using optional stainless steel cover strips or on adjacent walls using corner plinths (ordered as extra - please contact the Commercial Washrooms sales team). This trough can be made to bespoke measurements (increased lead times).
1.2m urinal troughs are suitable for up to 2 users, 1.8m urinal troughs are suitable for up to 3 users and 2.4m urinal troughs are suitable for up to 4 users.
Urinal Troughs are popular in male toilet rooms prone to high footfall and potential vandalism. Frequently installed in school toilets, entertainment venues as well as public toilet rooms.
These troughs are manufactured in the UK and have an outstanding reputation for quality.
Dimensions:
- Overall Height: 1065mm
- Depth from rear wall: 265mm
- Length: 1200mm, 1800mm or 2400mm as standard. Bespoke lengths available (POA)
Product Codes:
- SAN013-1200-LBI: 1.2m urinal trough with concealed plastic cistern (back inlet) and left-hand waste outlet
- SAN013-1200-RBI: 1.2m urinal trough with concealed plastic cistern (back inlet) and right-hand waste outlet
- SAN013-1800-LBI: 1.8m urinal trough with concealed plastic cistern (back inlet) and left-hand waste outlet
- SAN013-1800-RBI: 1.8m urinal trough with concealed plastic cistern (back inlet) and right-hand waste outlet
- SAN013-2400-LBI: 2.4m urinal trough with concealed plastic cistern (back inlet) and left-hand waste outlet
- SAN013-2400-RBI: 2.4m urinal trough with concealed plastic cistern (back inlet) and right-hand waste outlet
