Delabie Infra-red Sensor Urinal Flush Control Kit (Single Station)
Typically 1-2 Working Days
Product Code: 428150
This individual urinal sensor flush valve manufactured by Douglas Delabie is ideal for installation to control the flush of a single urinal.
It is designed to operate directly from a mains water supply (no need for a cistern) either through a wall into a service area or within duct panelling (distance no greater than 150mm). Suggested uses and applications are within any public and commercial premises with 1 or more urinals where moderate to heavy use exists.
30 days free credit with
Buy Now, Pay Later, options at checkout
This individual urinal sensor flush valve manufactured by Douglas Delabie is ideal for installation to control the flush of a single urinal.
It is designed to operate directly from a mains water supply (no need for a cistern) either through a wall into a service area or within duct panelling (distance no greater than 150mm). Suggested uses and applications are within any public and commercial premises with 1 or more urinals where moderate to heavy use exists.
The system operates on a presence detection of the user by infrared beam (no need for hand movement/contact) which is adjustable by the installer. The Kit includes a concealed infrared detector on a chrome wall plate, an electronic module mains powered 230/12V 1.5m sensor cable, solenoid valve, filter and stop valve.
Please note: You will require a transformer kit (406220) with this urinal sensor; one transformer will suit up to 5no. urinal sensors. We highly recommend that a transformer is purchased otherwise the warranty on this product is void.
We recommend the installation of an air break valve (frequently referred to as a DC pipe interrupter) with any mains fed urinal flush systems (1 per urinal). This valve will prevent backflow to the mains water supply.
Key Features:
- Flush module activates after 3 sec. of the user moving away, avoiding inopportune flushing.
- Optional automatic 2 sec. pre-rinsing operation which rinses as the user arrives.
- Periodic rinsing every 12 hours after the last use which avoids creating vacuum in water wastes and bad smells.
- Activation doesn't require manual contact, avoiding the propagation of bacteria/germs carried by the hands.
- Water Savings from automatic shut-off and adjustable shut-off delay.
- No Servicing: stops urinals and drains clogging and avoids vacuums in water wastes thanks to periodic rinsing.
- Easy Maintenance with separate electronic control box with auto diagnostic LED™s.
- 3 Year Manufacturer™s Warranty.
