Cistermiser Standard Hydraulic Urinal Flush Control Valve - Hygiene Flush
This Cisternmiser Standard Hydraulic Urinal Flush Control Valve utilises a simple and innovative mechanism to save water by allowing the automatic flush cistern to fill up and flush when the washroom is in use.
30 days free credit with
Buy Now, Pay Later, options at checkout
This Cistermiser Standard Hydraulic Urinal Flush Control Valve utilises a simple and innovative mechanism to save water by allowing the automatic flush cistern to fill up and flush when the washroom is in use.
Installation of the Cistermiser standard valve onto the urinal cistern supply pipe will limit the flow of water to the urinal bowl, allowing flow of water into the cistern only when the washroom is in use.
This valve is available to purchase on it's own, or with a hygiene flush attachment. With the additional of the hygiene flush attachment the standard urinal Cistermiser is also able to perform a hygiene cycle or janitorial flush every 12 hours of inactivity to reduce unpleasant odours from the urinals and reduce the risk of blockages in the wastes even when the washrooms are not being used.
We also provide a version of this flush valve that is suitable for low pressure systems.
Satisfies the requirement under Schedule 2, Section 9, Paragraph 25 of the Water Regulations Advisory Scheme to install an approved urinal flush control with all auto-cisterns and urinals.
The Cistermiser range of hydraulic valves urinal flush controls are installed in-line with the water supply inlet pipe into the cistern and sense short term drops in pressure within the water supply. Each time a drop in pressure is identified the valve releases a measured amount of water into the cistern. The auto-syphon will flush the urinals once the required amount of water is in the cistern. The short term drops in water pressure the Cistermiser flush control senses are caused by the use of taps or toilet flushing within the washroom, which approximates the use of the urinals.
With an adjustable timer, the Cistermiser valve can remain opened or shut for varying periods, thereby changing the amount of time the cistern takes to fill up. The valve is activated by a sudden short term pressure drop in the system, caused by events such as taps turning on. When activated, the valve opens and water passes to the urinal cistern until the pressures on both sides of the valve are equalised. When the cistern is full the auto-syphon will flush.
More information is available in the data sheets attached.
Key Features:
- Automatic urinal flush control
- Cistermiser ensures compliance with the Water Regulations - WRAS approved product
- Saves water - reduces water bills and eco-footprint
- Unique patented hydraulic mechanism - no electrical supply or batteries required
- Fit and forget™ quality and reliability - virtually no maintenance
- Suitable for water pressures between 0.5 and 6.0 bar
- Mains water, or tank fed water above 5m head
- Cistermiser 3 year product manufacturer guarantee (upon product registration)
- Made in Britain
Product codes:
- STD - Cistermiser Standard Hydraulic Urinal Flush Control Valve
- STDIF - Cistermiser Standard Hydraulic Urinal Flush Control Valve with Hygiene Flush
-
